Pagid Racing E1151 in RSH42 compound brake pads for various Ginetta/ Mercedes cars
£173.95
PAGID Racing RSH compounds are developed to comply with the latest requirements in historic racing and meet or surpass all current ecological standards of the automotive industry. Available model years in the extensive application range starts in the late 50s and goes up to the 90s.
With their excellent release characteristics come very good modulation and controllability.
RSC brakepads have a low heat conductivity which gives them a wide operating temperature range.
Pagid RSH brakepads have slightly profressive in-stop friction behavior.
application range:
An excellent classic rally pad which is also very popular in small formula cars.
Description:
The characteristics of RSH 42 make this material appropriate for small formula cars. Furthermore you can use it as rear axle compound in combination with the RSH 29E on the front axle..
Pad fitting:
New brake pads must move freely in the caliper guides. Always use the appropriate pad shape to ensure proper fit.
When new pads are installed, always ensure that the pedal is pumped up to take up any caliper piston travel prior to driving the vehicle.
Brake pad bedding in:
In the first phase of the bedding in procedure, you have to create a perfect contact-pattern between disc and pad.
And this is how it works: you have to do about 10 stops with low pressure and low temperature from 150 km/h to approximately 80 km/h.
The distance between each brake stop should be between 600 and 800 meters.
Pad fade:
If the temperature between pad and disc gets too high, gasses build up an air cushion between pad and disc. The pedal remains stiff, but the stopping power is reduced.
Solutions are an improved cooling, change to a higher temperature range pad material or a higher mass brake disc.
Brake pad size:
A bigger pad does not mean a bigger stopping power.
But the greater heat capacity of the larger pad can improve modulation, wear rate and lead to more consistent performance.
Brake balance:
A perfect brake balance is important in order to reach a minimum stopping distance by maintaining good vehicle stability.
The bias setting can be done with either correct selection of the friction material and respective friction coefficients or also by race cars which are having a balance bar by adjusting the balance bar into the correct position.
Brake backingplate:
To guarantee a perfect connection between friction material and backing plate, PAGID Racing is using a specific retention system with brass studs that are welded directly to the backplate.
These brass studs are softer than the brake disc (rotor) and wear away as the pad is consumed causing no damage to the disc.
About Pagid Racing
PAGID Racing is the exclusive motorsport brand of the TMD Performance. As a member of the TMD Friction Group, TMD Performance is the worldwide sole distributor of PAGID Racing products and high performance brake pads for street legal cars.
The brake products are designed to produce the highest possible performance levels over a wide range of operating conditions, and are available in many different material formulations.
They fit most popular racing and high performance calipers and also may be fitted as an upgrade to many standard calipers for high performance cars.
In addition, PAGID Racing brake products are fitted as original equipment to some of the most prestigious and powerful production cars in the world including Audi, Bugatti, Ferrari and Porsche.
With the facilities in Leverkusen & Essen (Germany) and Troy (USA), TMD Performance is one of only a small number of companies capable of developing and manufacturing brake friction solutions according to customer-specific technical requirements in a short time.
Why buy from MS Motorsport?
MS Motorsport carries a large range Pagid brake pads in stock. Many BMW & Porsche trackday and racing teams know the way to MS Motosport if they require new pads or need advice about the brakes of their cars.
MS Motorsport supplies both professional race teams and trackday enthusiasts!
Please do not hesitate to contact us if you have any questions regarding brakepads for your car.
| SKU | E1151RSH42 |
|---|---|
| Brand | Pagid |
| manufacturer partnumber | E1151 |
| Brake pad compound | RSH42 |
| Make | Ginetta, Mercedes |
| Model | 190 2.3 16V, 190 2.5 16V, G15 |
| Build year | 1967, 1968, 1969, 1970, 1971, 1972, 1973, 1982, 1983, 1984, 1985, 1986, 1987, 1988, 1989, 1990, 1991, 1992, 1993 |
